Smart Floor Trap

Smart Floor Trap

The Smart Tile Drain is an innovative breakthrough in the floor grate designing. It redefines the way drainage pits look. Smart tile drain offers modern aesthetics and can be blended well with modern and innovative bathroom designs. Its unique design ensures a neat and crisp edge to surrounding floor tiles and provides a 5mm gap for surface water to escape which offers roughly twice discharge rates compared to normal grating. The design completely conceals the drainage pit. The centre tile recess causes the tile to visually merge with the surrounding tiles and the overall decor. Bathroom/ Floor drain is made of stainless steel 304, comes with a DN 100 outlet (2.5 deg slope), 0.9 l / sec flow rate, with removable door trap, adjustable SS304 upper body, stainless steel grating, can withstand load class K (300 kg), thermal resistance up to 90 °c.This floor drain is designed for both indoor and outdoor use.


  • Available in standard size of 150mm x 150mm
  • Complete Assembly made up of SS304 material.
  • Withstands loads up to 300 kg with locking system.
  • Comes with tiled or steel cover and a locking system.
  • Can be removed easily and quickly for cleaning.
  • Completely conceals the drainage pipes and enhances the visual appearance.
  • Provides ample space for water to escape.


  • Can be used for multiple locations like bathroom, kitchen, dry balcony, veranda, washing machine area, public drain area.
  • Numerous lid patterns available.
  • Manufactured in stainless steel 304 / 316.
  • Laser cut for precision and uncompromising quality.
